Product Details:
Payment & Shipping Terms:
|
| Item: | Epoxy Coated Wire Mesh Hydraulic Air Filters Support Layer 18*14 Mesh | Material: | Superior Steel Wire, Stainless Steel Wire, Aluminum Alloy Wire |
|---|---|---|---|
| Mesh: | 14X14, 16X14,, 16X16, 18X16, 18X18, 18X14, 20X20 | Wire Diameter: | 0.1-0.3mm |
| Roll Width: | 50mm-1300mm | Roll Length: | 10-400m |
| Color: | Black ,Gray ,White ,etc | Applications: | Support Layer Used In Hydraulic Or Air Filters |
| Highlight: | Hydraulic Air Filters Epoxy Coated Mesh,400m Length Epoxy Coated Wire Mesh,18*14 Epoxy Coated Wire Mesh |
||
Black Epoxy coated wire mesh hydraulic air filters support layer 18*14 mesh
Descriptions :
Anoxic annealed low carbon steel wire, stainless steel wire, aluminum alloy wire weave epoxy resin coating, weave plain
weave, epoxy resin coating, for a variety of color choice.it is also called Epoxy Coated Wire Mesh,Epoxy Coated Screen,Epoxy coated air filter mesh.
Quick details& Specifications :
Black epoxy coating is standard, but we can offer a variety of coating colors. Some common specifications include 18×14 Mesh .007”, 18×10 Mesh .007”, and 18×16 Mesh .011”. We can offer our epoxy coated wire cloth in rolls in varying widths and lengths up to 500 feet or more.
| Material : | High quality low carbon steel wire, SS wire, aluminum alloy wire. |
| Weaving pattern: | Plain Weave |
| Mesh : | 12x10 ,14x14 ,16×16, 18×16, 18×18, 18×14, 26x 22,24×24,30×30 |
| Diameter : | BWG30, 31, 32, 33, 34, 35, 36, 37, 38, 39.(0.1-0.3mm) |
| Roll Width : | 0.58 m, 0.754 m, 0.876 m, 0.965 m, 1.014 m,1.05 m,1.1 m, 1.22 m,1.25m etc. |
| Roll Length | 10m-400m |
Applications :
Epoxy Coated Wire Mesh products are mainly used in filter element for support layer .
